25 XAC (New)

Coastal

Adventure Beyond the Catch

Designed for the adventurer at heart, the KingFisher 25 XAC is purpose-built for families, cruisers, and anglers seeking unmatched versatility and comfort on the water. Combining the rugged functionality of a fishing boat with the cozy comforts of a cruising vessel, the XAC (Xtreme Adventure Crossover) series is perfect for overnight cruising, fishing, and coastal exploration.

The 25 XAC was crafted to cater to fishing families who desire more than just a fishing vessel. This compact cuddy cabin boat blends performance, comfort, and adaptability to redefine on-water adventure. Whether you’re cruising the Pacific Northwest or navigating the Great Lakes, the 25 XAC delivers unparalleled versatility for fishing and family fun.

LENGTH

25'2"

MAX HP

300

BEAM

8' 6"

Starting at: $141,876

Estimated total includes base boat, engine, pre-rig, controls, PDI, trailer & freight. Price does not include tax, prep, or dealer discounts. Current pricing is based on 2025 model year, please see your local dealer for availability and additional pricing detail.

Specifications

  • SeriesCoastal
  • Model25 XAC (New)
  • Length Overall25'2"
  • Beam8' 6"
  • Maximum HP300
  • Cabin Length88"
  • Cabin Headroom6' 3"
  • Transom Fish Locker34 USG
  • Transom Weight Limit1200 lbs
  • Cockpit Floor Fish Locker39 USG
  • Approx Dry Weight3913 lbs
  • DeadriseVariable 16°
  • Fuel Capacity322 L / 85 USG
  • Side0.160"
  • Side Height38"
  • Bottom0.190"
  • Bottom Width80"

Standard Hull Features

  • Exclusive Pre-Flex® hull technology
  • Full length performance HD delta keel
  • Engineered full length reverse chines
  • Performance fully welded lifting strakes and heavy duty keel guard
  • Formed compound angle box stringers / full length
  • Single piece hull sides integrated into the swim platform with upswept bow and wide formed flat gunnels
  • Bow anchor rope locker with hawse pipe and welded aluminum anchor roller
  • Under deck drum winch compartment
  • Foul weather bow coamings with hawse rings
  • Welded aluminum hard top with overhead forward & side storage trays
  • Forward sloping windshield with direct bonded glass windshield,
  • 2 bonded sliding side windows with screens
  • Integral aluminum cockpit roof extension
  • Full width integrated external motor bracket with transom platform
  • Folding transom step-thru
  • Closed cell polyurethane foam for sound dampening
  • 2 aft cockpit floor fish lockers with pump outs
  • 2 full length cockpit side storage trays
  • Welded bow eye with stainless sleeve and 2 welded aluminum stern eyes
  • Transom bench seat
  • 7 x 9″ heavy duty welded bow and stern cleats
  • Aluminum Cockpit Floor with KingDeck
  • Aft cockpit bolster gunnel pads

Trailer / Standard with Boat Package

  • 7500 lb galvanized tandem-axle bunk trailer, surge disc brakes, alum wheels

Standard Paint & Graphics

  • Speckle painted gunnels, cabin walls & interior with color matched painted roof accent
  • Exterior full side paint color choice with KingFisher standard decal

Standard Exterior Features

  • Stainless bow grab rails & aft cockpit grab rails
  • Bolt on sacrificial hull anodes
  • Aft cockpit LED decklight
  • Port & starboard pantographic windshield wipers
  • Shipping protection cover
  • Rear quarter bulkhead on starboard side w/ window
  • Aux Station Ready
  • Roll up drop curtain with dual roll up doors
  • Tinted side windows

Standard Interior Features

  • V berth cushion & interior lighting
  • V berth lockable storage space with sliding door
  • V berth cabin roof deck hatch
  • Fishmaster XL captain seat with slider
  • 2 Side facing bench seats, 1 forward facing passenger bench seat. All equipped with under seat storage.
  • Speckle painted interior with carpeted lower hull sides
  • Cabin in-floor storage locker
  • XL Dash panel for flush mount electronics
  • Aluminum overhead radio shelf
  • Cold weather interior cabin roof & wall liner
  • Carbon Monoxide Detector

Standard Systems Features

  • Hydraulic steering with stainless steel wheel
  • Electric fuel gauge
  • 3x USB A/C combination outlets
  • Navigation lights package
  • Electric horn
  • Battery isolator switch with buss bar & battery trays
  • 2 Electric 1100 gph bilge pumps with auto switch
  • Premium dash switch panel with resettable circuit breakers
  • Interior cabin lighting
  • Heavy duty color coded wire harness with water tight connections
  • 9″ x 10″ Aluminum trim tabs with indicators

Crossover Dinette and Galley Package

  • Starboard side aluminum galley cabinet with stainless sink, faucet refrigerator and fresh water holding tank
  • Dinette with dual flip back seats with storage underneath, and dining table

Aft Cabin Bulkhead Full View Package

  • Full view 48″ wide opening dual glass french door

Adventure Package

  • Aluminum roof mounted rod holders (4 per side, 8 total)
  • Stainless steel exterior cabin roof rails
  • High pressure wash down system
  • Starboard fish net holder

BUILD
YOUR KINGFISHER

Build and price your dream KingFisher boat to your exact specifications and preferences with our boat builder.

Build Your 25 XAC (New) Free Dealer Quote
